70-90-M2 Series
Thermal Break
A heavy-duty thermal break profile system for large-format AHU panel frames with 90 mm panel thickness, M2 variant.
Thermal Break
VDI 6022 Certified
System Specs
Panel Thickness
90 mm
Frame Architecture
Thermal Break
Nylon Certification
VDI 6022 Standard
Components Table
Component
Part Code
Material
Corner Profile
TB ALC 7090 M2
Aluminium EN AW6063
Corner Joiner
TB NYC 7090 M2
Nylon VDI 6022
Omega Profile
TB ALO 7090 M2
Aluminium EN AW6063
Omega Joiner
TB NYO 7090 M2
Nylon VDI 6022
Product Components
Corner Profile
Part Code
TB ALC 7090 M2
Material
Aluminium EN AW6063
Corner Joiner
Part Code
TB NYC 7090 M2
Material
Nylon VDI 6022
Omega Profile
Part Code
TB ALO 7090 M2
Material
Aluminium EN AW6063
Omega Joiner
Part Code
TB NYO 7090 M2
Material
Nylon VDI 6022
